Model Viewer is a powerful browser through which users can quickly view large assemblies. It is also convenient to obtain the required data through component number or attribute information. This visual database management brings great convenience to users.

Manufacturers can use Model Viewer to directly browse the manufacturing information of 3D data output by CADdoctor/ASFALIS, which saves a lot of CAD software costs.

Import and export

1. Supports dimensions of 3D models, PMI, annotations on NX, CATIA, I-DEAS and PROE platforms

2. User-defined attributes;

3. Screen snapshots, coordinate axes, sectional views, and etc.

4. 3D model hierarchical and group level display.

Import and export

1. Export components and attribute list, annotate information, and etc.

2. Export the assembly structure tree of assembly parts.

3. Import other components or accessories;

4. Import the results of ASFALIS module analysis, such as: PDQ detection, comparison, interference check, and etc.

5. Export 2D decomposition diagram.

Editing and Searching

1. ModelViewer supports users to edit the component name and assembly tree structure of assembly parts. It can add or delete components in assembly, and can move and arrange the location of components.

2. Users can add customized comments or sizes.

3. Users can search components according to their names or attributes.

Interference Check and Measuring Dimensions

1. ModelViewer can import and export the inspection results, and can calculate the interference volume and the center of the interference part.

2. Users can measure 3D data in ModelViewer, including distance, diameter, angle and etc.
