2D drawings are still widely used in
manufacturing industry. Drawing Validator can automatically compare 2D
drawings, eliminate the tedious work of manual detection of 2D drawings
changes, and simplify the process from design to manufacturing.
Information verification based on CAD Model
Compare geometric and non-geometric information
Identify redundant differences, such as the location of views, PMI, and BOM tables
Inspection standards and tolerances can be adjusted to meet customer needs
List all detected differences by element type
Navigate to selected differences
Highlight differences
Display numeric values, such as dimensions and annotations
Export result report in HTML format
Installation and permission are not required to view the results
Simplify communication between relevant personnel
Improve the efficiency of project change communication
Design engineers can better express changes and quickly reflect engineering changes, thus shortening the delivery time to a large extent and avoiding unnecessary rework and delays.
